Glass Fiber Pleated Filter Bags Fiber Dust Bags

Basic Info.

Model NO.	001
Filter Bag Environment	High-Temperature
Filter Bag Sectional Shape	Round Bag
Gram Weight	Customizable
Filtration Grade	Medium Filter
Usage	Dust Filter, Air Filter
Material	Synthetic Fiber
Transport Package	Carton Packaging
Specification	Regular size; Customizable
Trademark	SFFILTECH
Origin	Shanghai
HS Code	5911900090
Production Capacity	50000pieces

Product Description

Glass fiber pleated filter bags fiber dust bags
Pleated filter bag, also known as star filter bag, is a new type of filter bag which can be used on pulse bag filter. its dust removal skeleton needs special design, and it can used with other supporting components.
Performance characteristics:
1. It can directly replace the existing dust bag of bag filter, and the main structure of dust removal equipment does not need to be reformed. After replacement, the filtration area can be increased by 50-150%;
2. It can significantly reduce the pressure difference of the system, thus improving the overall performance of the system and the life of the dust removal bag;
3, It can greatly reduce the frequency of ash removal or extend the ash removal intervals
4. Compared with traditional filter bag, pulse ash removal efficiency is obviously improved due to the special structure of pleated filter bag
5. The effective use area of dust removal filter bag increases, and the airflow rising speed between ash removals filter bag decreases, greatly optimizing the online ash elimination effect
6. The special design of folding filter bag itself and dust cage greatly reduces the fatigue damage and inter-discharge caused by pulse spraying;
7. Due to the dust cage has no horizontal support ring and its large effective contact area, it can completely avoiding the direct impact on the dust removal filter bag;
8. As required, the length of folded filter bag can be shortened while the diameter of filter is increased, and the system operation can be optimized
9. Greatly reduce the lode of air consumption, air compressor and pulse valve;
10. The fan load is greatly reduced and the energy consumption of the system is significantly improved;
11. System maintenance cost, including energy consumption, auxiliary equipment, spare parts and labor, has been reduced significantly;
12. Can use any existing dust removal bag material that meets the requirements of the system;
13. Traditional dust removal filter bag can still be used as emergency spare part of pleated filter bag, but the corresponding dust cage should be used.

Application temperature

Material	Gramage	Thickness	Working Temperature	Max. Surge Temperature
	(g/m²)	(mm)	(ºC)	(ºC )
Polyester needle felt	500	1.8	≤130	150
PPS needle felt	500	1.8	≤190	230
Fiberglass	1000	2.1	≤280	300
Acrylic fibers	500	2	≤160	180
	800	2	≤280	300
